· Page mode parameters initialized at end of multiple barcodes command string
Sample multiple barcodes command string:
1b 40
Initialize
1d 6b ff 01 Begin multiple barcodes one line
1b 61 01 Center align
1d 68 40 Barcode height
1d 77 02 Barcode width
1d 48 02 Print HRI below
1d 6b 49 06 67 27 2d 2e 2d 2e Barcode 1, code 128
Set GS1 DataBar (formerly RSS) parameters
ASCII GS q a b c d e fL fH
Hexadecimal 1D 71 a b c d e fL fH
Decimal 29 113 a b c d e fL fH
a byte pixels per minimum unit, default 3, minimum 2, maximum 6 (value a applies
to parameters b, c, d)
b byte X undercut, default 0, can be set 0 to a-1
c byte Y undercut, default 0, can be set 0 to a-1
d byte separator height, default a, can be set a to a*2
e byte segment width, used only by GS1 Expanded, default 22, must be even
number 2 to 22
f word line height, used only by UCC128, default 25, can be set 1 to 500
Note: For GS1 DataBar commands, consult ISO/IEC 24721. For futher information, visit www.gs1.org.
· Parameters for alignment, height, width, and HRI can be set before or after 1D 6B FF 01 command
· No height restriction change from single line barcodes
· Quiet zone between barcodes = 10 * module width
· No text in between barcodes (results undefined)
· Upright, picket fence barcodes only, no upside down or ladder. Extended barcode printing for upside down and
ladder barcodes can be done in page mode if required.
· Slip/validation selection disabled in multiple barcodes command string
· Multiple barcodes command string disabled when slip/validation selected
· Page mode disabled in multiple barcodes command string
· Multiple barcodes command string disabled in page mode
