Chapter 2: Diagnostics and Configuration 13 Revision C 12/09
A798-PG00001C
For more information about See this section
Accessing the remote diagnostic tallies “Command descriptions” in Chapter 4: Programming commands
(Status commands: Transmit printer ID, remote diagnostics extension,
Hexadecimal 1D 49 40 n)
Print test and configuration menu samples will vary per model or printer
configuration. (Shown approximately 60% of size.)
When the printer is configured for USB, this
location will show either: “USB Driver Type: Native”
, “USB Driver Type: Printer Class”, or “USB Driver:
Comm Class”.
To enter Printer Config Menu :
1) Flip DIP switch #1 down
2) Reset the printer, while holding
the Paper Feed button down
Model number : A798-720D-TD00
Serial number : C073400014
Boot Firmware
Revision : V1.00
CRC : 08D3
P/N : 189-7940154A
Flash Firmware
Revision : V1.00
CRC : D70C
P/N : 189-7940155A
H/W parameters
Flash Memoriy Size : 2 Mbytes
Flash Logos/Fonts : 1152 kbytes
Flash User Storage : 64 kbytes
Flash Journal Size : 64 kbytes
SRAM Size : 128 kbytes
CPU Clock Freq. : 50 MHz
Head setting : C
Pre-Heating : Disabled
Print Density : 100%
Max Speed : 150 mm/sec
Paper Width : 80 mm
Max Power : 55 W
Knife : Enabled
Partial Cut : 125 steps
Paper Low Sensor : Disabled
Comm. Interface
RX Buffer Size : 4096
Interface type : RS232/USB
Parameters
Baud Rate : 115200
Data Bits : 8
Stop Bit : 1
Parity : NONE
Flow Control : DTR/DSR
Reception Errors : Ignore
USB Driver Type : Printer Class
USB Packet w/Error : Reject
Resident Code Pages : 437, 850, 852, 857, 858
860, 863, 865, 866
1252, 862, 737, 874
A715 CP850 Emulation : Disabled
Logo(s) defined : YES
User Char(s) defined : NO
Journal Unused : 64 kbytes
Diagnostice : OFF
*** A798 – Diagnostics Form ***
