CNB SDF1212CD User Manual
Page 33
4 Channel DVR User Guide
33
4-4. Playback mode
Figure 4.4.1. Playback mode screen
Button functions in Playback mode
ESC
Return to the previous menu screen, search list, or exit menu.
Press to rewind the footage at 1x, 2x, and 4x speeds. Reverse playback
speed is shown as -1x (normal), -2x (2 times normal), and -4x (4 times
normal) at the bottom right of the screen.
Jump/Step backward. – The playback position moves 60 seconds backward.
Press to play or pause recorded video.
Jump/Step forward –Playback position moves 60 seconds forward.
Press to fast forward the footage at 1x, 2x, and 4x speeds. Playback speed is
indicated as +1X, +2X, and +4X for normal, twice, and 4 times of the regular
speed at the bottom right of the screen.
BACKUP
Press the BACKUP button to archive the video into HDD.
