CNB SDF1212 - Manual (Page 41)

41
6-5-2. Main control panel
Displays the recording time of the selected data by adjusting
of scale in the middle of the bottom of the main user interface.
Click this icon to see live videos.
The calendar shows dates with recorded video in a light Blue
and the selected date in Red color.
Click this icon to capture a still image of recorded video.
Save Path: User can select or make a folder that captured
image is saved.
File: Enter file name of captured image.
File Format: Select file format from BMP or JPG.
Click this icon to set the beginning time for backup of the
recorded video in AVI format
Click this icon to set the ending time for backup of the
recorded video in AVI format
Click this icon to backup the recorded video in AVI format.
