54
Alarm Schedule
 Users are able to schedule the Alarm In deactivation period.
 Click ‘Alarm Schedule’ and the following screen will appear.
 Select the Alarm Input(s) to apply alarm in sensor deactivation according to Alarm schedule.
 Select the Hours to deactivate the alarm in sensor.
 Choose ‘OK’ to confirm setting.
4.4.5 Alarm Out
 Please click ( ) DEVICES>Alarm Out and the following screen will appear.
 The Alarm Out menu will allow user to give title and to select the type and duration of Alarm output.
 Click ( ) the keyboard icon on the right-hand side of each frame on Title column and the virtual keyboard will appear. Then,
please register the title of Alarm output.
 When a check box is marked  on No column, a corresponding Alarm output starts operating. However, if user does not
check the check box, the operation stops.
 Click ( ) each frame on Type column to select type of a corresponding Alarm output.
- NO: contact is normally open (Normally open)
- NC: contact is normally closed (Normally closed)
 User may change the type and duration of all Alarm output at a time by clicking the Type and Duration box on the menu tab.
 Choose ‘OK’ to confirm setting.
4.4.6 Serial In
NOTE
Please refer to “14 Serial In”.
