Page 12 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM
Mechanical
Mounting
Behind switch or outlet, or above light fixture in a single-gang
electrical box
Wires
Analog + 0-10V Control (Gray wire)
Analog - 0-10V Control (purple wire)
Line
Neutral
Load 1
Load 2
Set Button 1
Beeper Yes
Beep on button press Optional (off by default)
LED 1, green/red
Dimensions
171mm (wide), 30mm (high), 35mm (deep)
6.75-in. (wide), 1.2-in. (high), 1.4-in. (deep)
Weight 5.1 ounces
Operating Environment Indoors
Operating Temperature Range 32º F – 104º F (0º C – 40º C)
Operating Humidity Range 0-90% relative humidity, non-condensing
Storage conditions -4º F to +158º F (-20º C – 70º C)
Case Color White
Plastic UV stabilized polycarbonate
Electrical
Voltage 100-277VAC ±10%
Frequency 50Hz/60Hz
Maximum Load
0-10VDC for connection to dimmable ballast
Load 1; 100 to 277VAC / 5Amps
Load 2; 100 to 277VAC / 5Amps
Hardwired remote control RJ-10 Mini-modular jack four conductor
Hardwire port wiring
Pin 4
(Left side)
Pin 3 Pin 2
Pin 1
(Right side)
Ground Group 1 - 2 Group 3-4 12-15VDC
Hardwire port triggering
Group 1: triggers when switch between Pin 3 & 4 is closed
Group 2: triggers when switch between Pin 3 & 4 is opened
Group 3: triggers when switch between Pin 2 & 4 is closed
Group 4: triggers when switch between Pin 2 & 4 is opened
Retains all settings without power Yes, saved in non-volatile EEPROM
Load Type(s) Wired in ballasted dimming and non-dimming lighting loads
Retains all settings without power Yes, saved in Non-volatile EEPROM
Standby power consumption < 1 watt
Safety Approved ETL, CE, C-Tick
