Page 11 of 16 2475DA2, 2442-422, 2442-522 Rev: 1/21/2014 8:31 AM
Specifications
General
Product Name
Ballast Dimmer Relay – INSTEON Remote Control Ballast
Dimmer On/Off Switch (Dual-Band)
Brand INSTEON
Manufacturer Product Number
2475DA2 (US)
2446-422 (EU)
2446-522 (AUS/NZ)
UPC
813922011425 (US)
813922012897 (EU)
813922012903 (AZ)
Patent Number 7,345,998 US, International Patents Granted and Pending
Warranty 2 Years, Limited
INSTEON
INSTEON ID 1
INSTEON 400 responder groups and 1 controller group
Maximum Scene Memberships 400 (Combined Controller + Responder)
INSTEON Device Category
0x01 Dimmable Lighting Control (All Frequencies)
INSTEON Device Subcategory
2475DA2 (915MHz 0x25
2446-422 (869MHz) 0x3D
2446-522 (921MHz) 0x3E
Load brightness levels 32 locally (256 with software)
Status LED Green when load is on, red when load is off
LED brightness Adjustable, from off to bright via software
Local on-level (Dimming Mode) Adjustable, 32 fixed brightness levels or resume dim
Local ramp-rate (Dimming Mode)
Adjustable from 0.1 seconds to 9 seconds locally (0.1 seconds
to 9 minutes via software)
Local control Yes
Commands supported as controller On
Commands Supported as responder
On Off
Fast-on Fast-off
Begin bright Begin dim
End bright End dim
Incremental bright Incremental dim
Software Configurable Yes
RF Range Up to 50 meters open air
Phase detect beacon Yes
X10 Support Yes
X10 Addresses Any 1 of 256 (unassigned by default)
