Local Ramp Rate
The local ramp rate is the time it takes for the light(s) physically wired to In-LineLinc Dimmer to brighten
from off to 100% brightness and vice versa. The default ramp rate is 0.5 seconds, but it is adjustable from
0.1 seconds to 9 seconds locally or up to 8 minutes using software such as
HouseLinc .
Ramp rate is determined using the brightness level of the load. Refer to the chart below to determine the
ramping speed based on the load brightness.
Brightness Level
Ramp Rate in
Seconds
90-100% 0.1
77-87% 0.2
65-74% 0.3
52-61% 2.0
39-48% 2.0
26-35% 4.5
13-23% 6.5
1-10% 8.5
1% 9.0
1) Adjust the connected light(s) to the brightness level corresponding to desired ramp rate.
2) Double-tap In-LineLinc Dimmer’s Set button.
In-LineLinc Dimmer will double-beep.
3) Test the ramp rate settings by tapping In-LineLinc Dimmer’s ON/OFF buttons.
The connected light(s) will brighten and dim at the new rate.
4) If your double-tap was not fast enough, you may have accidentally changed the local on-level instead
of the local ramp rate. (Note: software such as HouseLinc allows you to remotely set on-levels and
ramp rates exactly as desired and consistently around the house.)
