Using In-LineLinc Dimmer
LEDs
LED Meaning
Solid green Load is on (at any dim level)
Solid red Load is off
Blinking green Unit is in linking mode
Blinking red Unit is in unlinking mode
Fast blinking red and optional
blink-on-traffic is turned on
Dimmer is off and INSTEON traffic received
Fast blinking green and optional
blink-on-traffic is turned on
Dimmer is on and INSTEON traffic received
Using the ON and OFF Buttons
The small button switches allows you to test the load and functions prior to final installation.
Button Tap Double-Tap Press and Hold
ON Ramp to on-level Fast on Brighten
OFF Ramp to off Fast off Dim
Set
Set the default
on-level
Sets the default
ramp rate
Starts linking
mode
Local On-Level
The local on-level is the brightness level at which the light(s) physically wired to In-LineLinc Dimmer turn
on. The default on-level is 100%, but it can be adjusted to any brightness level.
1) Use either In-LineLinc Dimmer’s ON or OFF buttons to adjust light to desired brightness.
2) Tap the In-LineLinc Dimmer’s Set button.
In-LineLinc will beep.
3) Test on-level settings by tapping In-LineLinc Dimmer’s ON/OFF buttons.
NOTE:
If In-LineLinc Dimmer’s Status LED is blinking, you held the Set button down too long and accidentally
placed it into linking mode, which times out after 4 minutes of inactivity. To manually exit linking mode, tap
any button except Set button.
