Dimmer to bridge the building’s electrical phases, use the following procedure to activate phase bridging
detection mode:
1) Start phase bridging detection mode by tapping In-LineLinc Dimmer’s Set button four times quickly.
In-LineLinc Dimmer will begin beeping and setup LED will be solid green .
2) Check the LED behavior of the “other” dual-band devices.
a) If it is blinking green , it is within range and not on the same electrical phase. Go to step 3.
b) If it is not blinking green , try moving the device, check other devices or begin the test from a
different device.
3) Tap In-LineLinc Dimmer’s Set Button.
In-LineLinc Dimmer stops beeping and LED returns to previous state.
Other devices’ LEDs will stop blinking in a few seconds.
Power Restoration
In-LineLinc Dimmer stores all of its scenes, properties, etc. in its internal non-volatile memory. As such, all
settings are retained after a power outage. Upon power restoration, In-LineLinc Dimmer will return its
connected load and all LEDs to their states prior to power outage.
X10 Programming
Instructions on setting X10 primary address and scene addresses can be found online at
http://www.smarthome.com/insteon-x10-programming.html .
Factory Reset
Factory Reset clears all user settings from In-LineLinc Dimmer including INSTEON Scenes, On-Levels,
Ramp Rates, X10 addresses, etc.
Option 1
1) If possible, remove all scene memberships prior to performing the factory reset.
2) Press and hold In-LineLinc Dimmer’s Set button until it beeps.
LED will blink green .
3) Press and hold In-LineLinc Dimmer’s Set button until it beeps again.
In-LineLinc Dimmer’s LED will blink red .
4) Double-tap In-LineLinc Dimmer’s Set button, then press and hold until the long beep stops.
In-LineLinc Dimmer will emit a long beep and its LED will turn off.
The connected load will turn on.
Option 2 – partner required
1) If possible, remove all scene memberships prior to performing the factory reset.
2) Turn off circuit breaker.
3) While pressing and holding In-LineLinc Dimmer’s Set button (do not let go), have a partner turn on
the circuit breaker.
As you continue to press and hold, In-LineLinc Dimmer will emit a long beep.
4) Continue to press and hold Set button until long beep stops, then release.
In-LineLinc Dimmer will double-beep and its LED will turn green .
The connected load will turn on.
