background image

Page 9 of 24

Rev: 1/21/2014 7:36 AM

Using KeypadLinc

LEDs

LED

Meaning

Brighter

On

Dim

Off

Button Taps

Button Type

Button LED State

before Tap

Effect of Tap

Effect of Double-tap

Toggle

Off

Turn Scene

Members On

Turn Scene Members On Instantly

Toggle

On

Turn Scene

Members Off

Turn Scene Members Off Instantly

Always On

Either

Turn Scene

Members On

Turn Scene Members On Instantly

Always Off

Either

Turn Scene

Members Off

Turn Scene Members Off Instantly

Notes:

1) The connected light(s) will react just like Scene Responders to button taps of MAIN (when using an

8-button KeypadLinc) and On or Off (when using a 6-button KeypadLinc)

2) LED will mimic the on/off status of a dimmer whose Scene level is 100% bright
3) ON button on a 6 button KeypadLinc is an “Always On” button while OFF button is an “Always Off”

button. Other buttons are toggle by default.

Button Tap / Press and Holds

Button Type

Button LED

before Tap

Effect of First

Press and Hold

Effect of Subsequent Press and Holds

Toggle

Off

Brighten Scene until

release

Opposite of last Press and Hold

(e.g. if last was brightening, it will dim)

Toggle

On

Dim Scene until

release

Opposite of last Press and Hold

(e.g. if last was brightening, it will dim)

Always On

Either

Brighten Scene until release

Always Off

Either

Dim Scene until release

Local On-Level

The Local On-Level is the brightness that the light(s) physically wired to KeypadLinc will come on at when
turned on locally. The default is 100%.

Local On-Level can be set to any one of 33 settings

32 fixed brightness levels (3% to 100%)
Or “Resume Bright”
• Previous brightness level is stored when turned off and recalled to that level
brightness when turned back on
