Page 15 of 18 Rev: 1/21/2014 7:34 AM
Warranty Two years, limited
Operation
LED 1 dimmable white status LED
Operation Modes INSTEON only, X10 only, INSTEON and X10 combo
Combo Mode Message Order INSTEON, INSTEON cleanup, X10
Multi-Way Circuit Support
One ToggleLinc Relay controls load, Cross-Link any number of
ToggleLinc Relays or other INSTEON Controllers
Setup Memory Non-volatile EEPROM
INSTEON
INSTEON Address 1 hard-coded out of 16,777,216 possible
Maximum Scene Memberships 417
INSTEON Powerline Frequency 131.65KHz
INSTEON Minimum Receive Level 10mV
INSTEON Messages Repeated Yes
Mechanical
Paddle Type
Toggle
Wire Nuts
3 included
Mounting
Mounts in single or multiple-ganged junction box.
Wires
Line (black)
Load (red)
Neutral (white)
Ground (bare copper)
Dimensions 4.14" H x 1.73" W x 1.4" D
Weight 3.6 oz.
Operating Environment Indoors
Operating Temperature Range 32°F to 104°F
Operating Humidity Range Up to 85% relative humidity
Electrical
Voltage 120 volts AC +/- 10%, 60 Hertz, single phase
Power Wire Leads
6", 14 AWG (black and red) and 18 AWG (for white), stranded,
600V, 105°C insulation, ends stripped and tinned, Line (black),
Load (red), Neutral (white)
Ground Lead 6”, 14 AWG, stranded, bare copper
Load Type(s) Wired-in incandescent lighting and inductive loads
Maximum Load 480W (for incandescent loads); 15 Amps
Standby power consumption 0.67 watts
Certifications Safety tested for use in USA and Canada (ETL #3017581)
X10 Features
X10 Primary Address 1 optional (comes unassigned)
