2474DWH- Rev: 1/21/2014 7:30 AM

Local Control

Follow these instructions to control the light/load (as well as any responders) from the dimmer paddle.

























INSTEON Setup

Some products have subtle differences in their setup procedures. Please refer to the other device’s
owner’s manual for details.

INSTEON Controllers, Responders and Links

Let’s define a few terms.

• The INSTEON “transmitter” is called a controller.
• The INSTEON “receiver” is called a responder.
• The association between the controller and responder is called a link.

Connected Light and Responders

Paddle

Tap

Press and hold

Double-tap

LED

Top

On

(ramped)

Brighten

(until release or 100%)

On

(instant)

White

Bottom

Off

(ramped)

Dim

(until release or off)

Off

(instant)

White

(in

bottom

position)

Controller

Responder

Link

Tap for ON, Press and hold to brighten

Tap for OFF, Press and hold to dim
