Page 13 of 15

2474DWH- Rev: 1/21/2014 7:30 AM

INSTEON device subcategory

0x24

X10

No X10 Support: INSTEON RF-only product

Mechanical

Mounting

Single gang electrical box

Wires

Black – line (16 gauge)
Red – load (16 gauge)
Copper – ground (16 gauge)

Color

White paddle (color change kits available), clear back case

Set button

1, clear

Air Gap

Yes (Set button pulled out)

Plastic

UV stabilized polycarbonate

Beeper

Yes

Beep on button press

Optional (off by default)

LEDs

9 white brightness LEDs, 1 green/red status LED

Dimensions

4.1" H x 1.8" W x 1.2" D

Weight

3.6oz

Operating environment

Indoors

Operating temperature range

32

o

to 104

o

F (0

o

to 40

o

C)

Operating humidity range

0-90% relative humidity

Storage temperature range

-4

o

to 158

o

F (-20

o

to 70

o

C)

Electrical

Voltage

120VAC ±10%, split single phase

Frequency

60Hz

Load type(s)

Wired-in incandescent lighting

Maximum load

600 watts

Minimum load

25 watts

User replaceable fuse

No

Hardwired remote control

No

Retains all settings without power

Yes, saved in non-volatile EEPROM

Standby power consumption

< 1 watt

Certifications

FCC, IC Canada

FCC ID

SBP2474DWH

Safety approval(s)

ETL (Intertek Testing Services)
