Programming
178
7" Modero Widescreen Touch Panels
Dynamic Image Commands
The following is a listing and descriptions of Dynamic Image Commands.
Dynamic Image Commands
^BBR
Set the bitmap of
a button to use a
particular
resource.
Syntax:
"'^BBR-
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
resource name = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel,"'^BBR-700,1,Sports_Image'"
Sets the resource name of the button to ’Sports_Image’.
^RAF
See page 179.
^RFR
Force a refresh for
an image only if it
is in the current
view.
Syntax:
"'^RFR-
Variable:
resource name = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel,"'^RFR-Sports_Image'"
Forces a refresh on ’Sports_Image’.
^RFRP
Force a refresh for
a given resource
regardless of
current view.
This command
can be used by
programmers to
prefetch images
that will be
needed soon.
Syntax:
“’^RFRP-
Variable:
resource name = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel, “’^RFRP-DoplerRadarDFW’”
Performs an update or prefetch on the resource named “DoplerRadarDFW”, even if the
image is not in the current view.
^RMF
Modify an
existing resource.
Syntax:
"'^RMF-
Variable:
resource name = 1 - 50 ASCII characters
data = Refer to the table in the RAF command for more information.
Example:
SEND_COMMAND Panel,"'^RMF-Sports_Image,%ALab_Test/
Images%Ftest.jpg'"
Changes the resource ’Sports_Image’ file name to ’test.jpg’ and the path to ’Lab_Test/
Images’.
^RSR
Change the
refresh rate for a
given resource.
Syntax:
"'^RSR-
Variable:
resource name = 1 - 50 ASCII characters.
refresh rate = Measured in seconds.
Example:
SEND_COMMAND Panel,"'^RSR-Sports_Image,5'"
Sets the refresh rate to 5 seconds for the given resource (’Sports_Image’).
