Programming
145 7" Modero Widescreen Touch Panels
"^" Button Commands (Cont.)
^BMI
Set the button
mask image.
Mask image is used to crop a borderless button to a non-square shape. This is typically
used with a bitmap.
Syntax:
"'^BMI-,,'"Variable: variable text address range = 1 - 4000.button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).mask image = Graphic file used.Example:SEND_COMMAND Panel,"'^BMI-530,1&2,newMac.png'"Sets the button with variable text 530 ON/OFF state mask image to 'newmac.png'.^BMLSet the maximum
length of the text
area button.If this value is set to zero (0) there is no max length. The maximum length available is
2000. This is only for a Text area input button and not for a Text area input masking button.Syntax: "'^BML-,'"Variable: variable text address range = 1 - 4000.max length = 2000 (0=no max length).Example:SEND_COMMAND Panel,"'^BML-500,20'"Sets the maximum length of the text area input button to 20 characters.^BMPAssign a picture to
those buttons with
a defined address
range.Syntax: "'^BMP-,,picture>'"Variable: variable text address range = 1 - 4000.button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).name of bitmap/picture = 1 - 50 ASCII characters.Example:SEND_COMMAND Panel,"'^BMP-500.504&510.515,1,bitmap.png'"Sets the OFF state picture for the buttons with variable text ranges of 500-504 & 510-515.^BNCClear current
TakeNote
annotations.Syntax: "'^BNC-,'"Variable: variable text address range = 1 - 4000.command value = (0= clear, 1= clear all).Example:SEND_COMMAND Panel,"'^BNC-973,0'"Clears the annotation of the TakeNote button with variable text 973.
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
mask image = Graphic file used.
Example:
SEND_COMMAND Panel,"'^BMI-530,1&2,newMac.png'"
Sets the button with variable text 530 ON/OFF state mask image to 'newmac.png'.
^BML
Set the maximum
length of the text
area button.
If this value is set to zero (0) there is no max length. The maximum length available is
2000. This is only for a Text area input button and not for a Text area input masking button.
Syntax:
"'^BML-,'"
Variable:
variable text address range = 1 - 4000.
max length = 2000 (0=no max length).
Example:
SEND_COMMAND Panel,"'^BML-500,20'"
Sets the maximum length of the text area input button to 20 characters.
^BMP
Assign a picture to
those buttons with
a defined address
range.
Syntax:
"'^BMP-,
picture>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
name of bitmap/picture = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel,"'^BMP-500.504&510.515,1,bitmap.png'"
Sets the OFF state picture for the buttons with variable text ranges of 500-504 & 510-515.
^BNC
Clear current
TakeNote
annotations.
Syntax:
"'^BNC-,'"
Variable:
variable text address range = 1 - 4000.
command value = (0= clear, 1= clear all).
Example:
SEND_COMMAND Panel,"'^BNC-973,0'"
Clears the annotation of the TakeNote button with variable text 973.
