AMX Modero NXD-700Vi - Manual (Page 146)

Full Duplex Intercom
124 7" Modero Widescreen Touch Panels
Sample Intercom Page (Cont.)
No. Name Description Channel
Port:Code
Address
Port:Code
Level
Port:Code
7 Panel Directory Room Name The name of a panel in the
intercom directory. You can call
the panel, enact privacy
against the panel and monitor
the panel.
1:1 1:1
8 Panel Directory Room Name The name of a panel in the
intercom directory. You can call
the panel, enact privacy
against the panel and monitor
the panel.
1:2 1:2
9 Panel Directory Room Name The name of a panel in the
intercom directory. You can call
the panel, enact privacy
against the panel and monitor
the panel.
1:3 1:3
10 Panel Directory Room Name The name of a panel in the
intercom directory. You can call
the panel, enact privacy
against the panel and monitor
the panel.
1:4 1:4
11 Panel Directory Room Name The name of a panel in the
intercom directory. You can call
the panel, enact privacy
against the panel and monitor
the panel.
1:5 1:5
12 Call Panel Display only; indicates the
panel is currently in a call. 1:21
13 Call Panel Display only; indicates the
panel is currently in a call. 1:24
14 Call Panel Display only; indicates the
panel is currently in a call. 1:27
15 Call Panel Display only; indicates the
panel is currently in a call. 1:30
16 Call Panel Display only; indicates the
panel is currently in a call. 1:33
17 Panel Privacy Display only; indicates the
panel has privacy enabled. 1:22
18 Panel Privacy Display only; indicates the
panel has privacy enabled. 1:25
19 Panel Privacy Display only; indicates the
panel has privacy enabled. 1:28
20 Panel Privacy Display only; indicates the
panel has privacy enabled. 1:31
21 Panel Privacy Display only; indicates the
panel has privacy enabled. 1:34
22 Monitor Panel Display only; indicates the
panel is being monitored by
another panel. 1:23
23 Monitor Panel Display only; indicates the
panel is being monitored by
another panel. 1:26
