A.2 sc60 modbus registers (continued) – Hach-Lange SC 60 User Manual
Page 59
55
Setup/Relay
3/Timer
Duration Time
40166
Unsigned
Integer
1
R/W
Sets the timer on duration time (sec)
Setup/Relay
3/Timer
Period Time
40167
Unsigned
Integer
1
R/W
Sets the period between timer on events
(mins)
Setup/Relay
3/Timer
Off Delay
40168
Unsigned
Integer
1
R/W
Sets the time the affected Sensor outputs
are held/transferred after the timer turns
off (sec)
Setup/Relay
3/Status
Level
40169
Unsigned
Integer
1
R/W
Sets the status level which will trigger
the relay
Comm/Net Card
Mode
40170
Unsigned
Integer
1
R/W
Sets the Modbus mode
(0 = RTU; 1 = ASCII)
Comm/Net Card
Baud
40171
Unsigned
Integer
1
R/W
Sets the Modbus baud rate (0 = 9600; 1 =
19200; 2 = 38400; 3 = 57600;
4 = 115200)
Comm/Net Card
Stop Bits
40172
Unsigned
Integer
1
R/W
Sets the number of stop bits (1.2)
Comm/Net Card
Data Order
40173
Unsigned
Integer
1
R/W
Sets the register data order for floats
(0 = Normal; 1 = Reversed)
Comm/Net Card
Min Response
Time
40174
Unsigned
Integer
1
R/W
Sets the minimum response time
(0 to 30 sec)
Comm/Net Card
Max Response
Time
40175
Unsigned
Integer
1
R/W
Sets the maximum response time
(100 to 1000 sec)
Comm/Net
Card/Addresses
sc60
40176
Unsigned
Integer
1
R/W
Sets the sc60 Modbus Address
Comm/Net
Card/Addresses
Sensor 1
40177
Unsigned
Integer
1
R/W
Sets the Sensor 1 Modbus Address
Comm/Net
Card/Addresses
Sensor 2
40178
Unsigned
Integer
1
R/W
Sets the Sensor 2 Modbus Address
Comm/Net
Card/Stats
Good
Messages
40179
Unsigned
Integer
2
R/W
Number of good messages
Comm/Net
Card/Stats
Bad Messages
40181
Unsigned
Integer
2
R/W
Number of failed messages
Comm/Net
Card/Stats
% Good Mesg
40183
Float
2
R/W
% of good messages
Comm/Service
Port
Mode
40185
Unsigned
Integer
1
R/W
Sets the Modbus mode (0 = RTU;
1 = ASCII)
Comm/Service
Port
Baud
40186
Unsigned
Integer
1
R/W
Sets the Modbus baud rate (0 = 9600;
1 = 19200; 2 = 38400; 3 = 57600;
4 = 115200)
Comm/Service
Port
Stop Bits
40187
Unsigned
Integer
1
R/W
Sets the number of stop bits (1.2)
Comm/Service
Port
Data Order
40188
Unsigned
Integer
1
R/W
Sets the register data order for floats
(0 = Normal; 1 = Reversed)
Comm/Service
Port
Min Response
Time
40189
Unsigned
Integer
1
R/W
Sets the minimum response time
(0 to 30 sec)
Comm/Service
Port
Max Response
Time
40190
Unsigned
Integer
1
R/W
Sets the maximum response time
(100 to 1000 sec)
Comm/Service
Port/Addresses
sc60
40191
Unsigned
Integer
1
R/W
Sets the sc60 Modbus Address
A.2 sc60 Modbus Registers (continued)
Group Name
Tag Name
Register #
Data
Type
Length
R/W
Description
