27
Section 4 Operation
4.1 Using the Keypad
The front of the controller is shown in Figure 22 . The keypad
consists of the eight keys as described in Table 7: .
Table 7: Controller Key Functions/Features
4.2 Controller Display Features
When a sensor is connected and the controller is in measurement
mode, the controller automatically identifies the connected sensors
and displays associated measurements.
Figure 22 Front of the Controller
1 Instrument display 4 RIGHT, LEFT, UP, and DOWN keys
2 BACK key 5 HOME key
3 MENU key 6 ENTER key
Number Key Function
2 Moves back one level in the menu structure.
3
Moves to the main menu from other menus. This key is not active in menus where a selection or
other input must be made.
4 Navigates through the menus, changes settings, and increments and decrements digits.
6
Moves to the Main Measurement screen from any other screen. This key is not active in menus
where a selection or other input must be made.
7 Accepts an input value, updates, or accepts displayed menu options.
sc60
1
2 6
3 7
4
