T W - 6 0 P U B L I C S A F E T Y R A D I O I N T E R F A C E
2 - 4
Table 4: Matrix Cables Required for Each TW-60 Unit
The matrix audio RJ-45 jack pinout from the TW-60 to the Clear-Com matrix
communications system is as follows:
Table 5: Matrix Audio RJ-45 Jack Pinout
TW-60 UNITS 730239 CABLES 730240 CABLES 730241 CABLES
Channels 1 - 4 4 1
Channels 5 - 8 4
Channels 9 - 12 4 1
Channels 13 - 16 4
PIN FUNCTION
1 Not used
2 Not used
3 Audio to matrix +
4 Audio from matrix +
5 Audio from matrix -
6 Audio to matrix -
7 Not used
8 Not used
