© Published by permission of the copyright owner – DO NOT COPY or TRANSMIT 7 70278501 (EN)
Installation/Operation Supplement
Installation
Specifications and Dimensions
Specifications 50 Pound 75 Pound
Noise level measured during operation at
operator position of 1 meter (3.3 feet) in front
of machine and 1.6 meters (5.2 feet) from
floor. 63 dBA 69 dBA
Net Weight (approximate):
kg (lbs.) 247
(545)
279
(615)
Cylinder Size:
mm (in.) 940 x 762
(37 x 30)
940 x 914
(37 x 36)
Cylinder Capacity (dry weight):
kg (lbs.) 22.7
(50)
34
(75)
Air Outlet Diameter:
mm (in.) 203
(8)
203
(8)
Maximum Static Back Pressure:
mbar (W.C.I.) 1.3
(0.5)
1.3
(0.5)
Maximum Airflow:
L/sec. (C.F.M.)
354
(750)
Gas/Steam 50 Hz 354 (750)
Gas/Steam 60 Hz 434 (920)
Electric
354 (750)
Motor Horsepower:
Nonreversing
Reversing
Fan
Cylinder
1/2
1/3
1/3
3/4
1/3
1/3
Gas Models
Gas Connection 1/2 in. NPT 1/2 in. NPT
Gas Burner Rating:
Mj/hr (Btu/hr) 126.6
(120,000)
174.1
(165,000)
Electric Models
Heating Elements Rating:
Kilowatts (kW) 21 kW (240 V/50 Hertz)
30 kW (other voltages)
30 kW
Steam Models
Steam Connection 3/4 in. NPT 3/4 in. NPT
Steam Coil Rating:
Btu/hr (Boiler Horsepower) 5.1
(177,500)
6.1
(210,300)
