Electrical connection locations – Alliance Laundry Systems Drying Tumbler 70278501R5EN User Manual
Page 13
© Published by permission of the copyright owner – DO NOT COPY or TRANSMIT
Installation/Operation Supplement
11
70278501 (EN)
Electrical Connection Locations
NOTE: These figures are approximate dimensions only.
TMB813N
TMB813N
GAS AND STEAM
ELECTRIC
A
B
B
A
Models
A
B
Gas and Steam
241 mm
(9.5 in.)
1613 mm
(63.5 in.)
Electric
483 mm
(19 in.)
1626 mm
(64 in.)
