Installation/Operation Supplement
23 70278501 (EN)
Control Instructions
Electromechanical Coin Control
CD and CX Control Suffixes
1. Set the TEMPERATURE selector at HIGH or
LOW, or anywhere between these settings.
Figure 5
2. Coin Drop Models: Insert the coin(s) in the coin
slot, turn the knob to the right and release it.
Figure 6
3. Press the PUSH TO START button and hold it in
for approximately three (3) seconds.
Figure 7
IMPORTANT: If the loading door or lint panel
door is opened during the cycle, the heating system
will shut off and the motor will stop. However, the
timer will continue to run. To restart the cycle, both
doors must be closed and the PUSH TO START
button must be pressed.
4. When the cycle is complete, open door and
remove the laundry.
TMB1976N
TMB1489N
HIGH
TEMPERATURE
LOW
INSERT QUARTER
TURN KNOB
25
TMB1488N
PUSH
TO
START
