Installation/Operation Supplement
Introduction
Model Identification
Information in this manual is applicable to these models:
Includes models with the following control suffixes:
Wiring Diagram
The wiring diagram is located in the junction or
contactor box.
Gas Steam/Thermal Oil Electric
50 Pound
CHD50G2-CU050L
CHD50G2-CU050N
DR50G2-BU050L
DR50G2-BU050N BU050T
CHD50S2-CU050S
CU050T
DR50S2-BU050S CHD50E2-CU050E
DR50E2-BU050E
75 Pound
CHD75G2-CU075L
CHD75G2-CU075N
DR75G2-BU075L
DR75G2-BU075N BU075T
CHD75S2-CU075S
CU075T
DR75S2-BU075S CHD75E2-CU075E
DR75E2-BU075E
3O – DX4 OPL
3V – DX4 vended
3X – DX4 prep for coin
CD – rotary coin drop
CX – prep for coin
DO – DMP OPL DV – DMP vended
DX – DMP prep for coin
MT– manual timer
QT – dual digital timer
R3 – reversing DX4 OPL
RD – reversing DMP OPL RQ – reversing dual digital timer
RT – reversing manual timer
SD – single drop
SX – single drop, prep for coin
