TABLE 2
RANGER QCT
ACTUATOR BENCHSET RANGES
TABLE 3
PREMIER EZO
ACTUATOR BENCHSET RANGES
TABLE 4
PREMIER UNLINED
ACTUATOR BENCHSET RANGES
* Model 148 included for clarity.
Valve Body Size
In. (DN)
Actuator
Model
*
Failure
Action
Benchset
Range
psig (Barg)
Supply
Pressure
psig (Barg)
Qty of Range
Springs
1", 1-1/2" & 2"
(25, 40 & 50)
48R-01 ATO-FC 5-15
(.34-1.03)
20
(1.4)
6
48D-01 ATC-FO
3" & 4"
(80 & 100)
148R-01 ATO-FC 5-13
(.34-.90)
20
(1.4)
4
148D-01 ATC-FO
4", 6" & 8"
(100,150, & 200)
148R-02 ATO-FC 10-26
(.69-1.79)
36
(2.5)
8
148D-02 ATC-FO
Valve Body Size
In. (DN)
Actuator
Model
*
Failure
Action
Benchset
Range
psig (Barg)
Supply
Pressure
psig (Barg)
Qty of Range
Springs
3" & 4"
(80 & 100)
48R-01 ATO-FC 5-15
(.34-1.03)
20
(1.4)
6
48D-01 ATC-FO
6"
(150)
148R-01 ATO-FC 5-13
(.34-.90)
20
(1.4)
4
148D-01 ATC-FO
8"
(200)
148R-03 ATO-FC 7.5-19.5
(.52-1.34)
27
(1.9)
6
148D-03 ATC-FO
10"
(250)
148R-02 ATO-FC 10-26
(.69-1.79)
30
(2.1)
8
148D-02 ATC-FO
Valve Body Size
In. (DN)
Actuator
Model
*
Failure
Action
Benchset
Range
psig (Barg)
Supply
Pressure
psig (Barg)
Qty of Range
Springs
3" & 4"
(80 & 100)
48R-01 ATO-FC 5-15
(.34-1.03)
20
(1.4)
6
48D-01 ATC-FO
6"
(150)
148R-01 ATO-FC 5-13
(.34-.90)
20
(1.4)
4
148D-01 ATC-FO
8" , 10"
(200, 250)
148R-03 ATO-FC 7.5-19.5
(.52-1.34)
27
(1.9)
6
148D-03 ATC-FO
