PCI-1710 /1710HG User's Manual
1.3 Specifications
Analog Input:
• Channels: 16 single-ended or 8 differential (software programma-
ble)
• Resolution: 12-bit
• On-board FIFO: 4K samples
• Conversion time: 8 µs
• Input range: (V, software programmable)
• Maximum Input Overvoltage: ±30 V
• Common Mode Rejection Ratio (CMRR)
PCI-1710
PCI-1710HG
Bipolar
±10, ±5, ±2.5, ±1.25,
±0.625
±10, ±5, ±1, ±0.5, ±0.1, ±0.05,
±0.01, ±0.005
Unipolar
0 ~ 10, 0 ~ 5, 0 ~ 2.5,
0 ~ 1.25
0 ~ 10, 0 ~ 1, 0 ~ 0.1, 0 ~ 0.01
PCI-1710
PCI-1710HG
Gain
CMRR
Gain
CMRR
0.5, 1
75dB
0.5, 1
75dB
2
80dB
10
90dB
4
84dB
100
106dB
8
84dB
1000
106dB
