Appendix A 8524 Counter Chip Functions 53
A.2 Counter Read/Write and
Control Registers
The 82C54 programmable interval timer uses four registers at
addresses BASE + 24(Dec), BASE + 26(Dec), BASE + 28(Dec) and
BASE + 30(Dec) for read, write and control of counter functions.
Register functions appear below:
Register Function
BASE + 24(Dec) Counter 0 read/write
BASE + 26(Dec) Counter 1 read/write
BASE + 28(Dec) Counter 2 read/write
BASE + 30(Dec) Counter control word
Since the 82C54 counter uses a 16-bit structure, each section of
read/write data is split into a least significant byte (LSB) and most
significant byte (MSB). To avoid errors it is important that you make
read/write operations in pairs and keep track of the byte order.
The data format for the control register appears below:
BASE+30(Dec) 82C54 control, standard mode
Bit
D7 D6 D5 D4 D3 D2 D1 D0
Value SC1 SC0 RW1 RW0 M2 M1 M0 BCD
Description:
SC1 & SC0 Select counter.
Counter SC1 SC0
0 0 0
1 0 1
2 1 0
Read-back command 1 1
