PCI-1710/1710HG User's Manual

I/O Connector Signal Descriptions

Signal

Name

Reference

Direction

Description

AI<0…15>

AIGND

Input

Analog Input Channels 0 through 15. Each

channel pair, AI (i = 0, 2, 4...14), can be
configured as either two single-ended inputs or
one differential input.

AIGND

-

-

Analog Input Ground. These pins are the

reference points for single-ended
measurements and the bias current return point

for differential measurement. The three ground

references (AIGND, AOGND, and DGND) are
connected together on the PCI-1710/1710HG
card.

DA0_ REF

AOGND

Input

Analog Output Channel 0 External

Reference. This is the external reference input

for the analog output channel 0 circuitry.

DA1_ REF

AOGND

Input

Analog Output Channel 1 External

Reference. This is the external reference input

for the analog output channel 1circuitry.

DA0 _OUT

AOGND

Output

Analog Output Channel 0. This pin supplies
the voltage output of analog output channel 0.

DA1 _OUT

AOGND

Output

Analog Output Channel 1. This pin supplies
the voltage output of analog output channel 1.

AOGND

-

-

Analog Output Ground. The analog output
voltages are referenced to these nodes. The
three ground references (AIGND, AOGND, and

DGND) are connected together on the PCI-

1710/1710HG card.
