18
Warranty: Limited 3-year warranty
3.2. Main component parts
1
1. FA703IPcamera with base
2. 4 assembly screws and plugs
3. Ethernet cable
4. DC supply
5. Software CD-ROM
6. User's manual
3.3. Connections
2
1. Ethernet port
2. DC connection
3. Reset opening
4. Camera installation
4.1. Connecting the camera
• Connect the adapter cable to the DC connection of the camera
3 . Then insert the adapter plug into the power outlet.
• Connect the included ethernet cable to the network port of
the camera 4 . Connect the other end of the ethernet cable to
your router. The green LED on the ethernet port will light up
when the camera is connected to the network. The LED on the
3. Technical specifications
3.1. General product specifications
Sensor: 1/4" Colour CMOS Sensor
Resolution: 640 x 480 pixels (300k pixels)
Viewing angle: 60 degrees
Minimal brightness: 0.5Lux @ F2.0
Video compression: MJPEG
Images per second: 25fps(VGA), 30fps(QVGA)
Power source: 230VAC/5VDC/2A Adapter
Energy consumption: 2,5W (Max.)
Temperature: -5°C ~ 55°C (23°F~131°F)
Minimal system requirements:
CPU: 2.0 GHZ or higher
Memory: 256 MB or higher
Video card: 64 MB or higher
Supported OS: Windows 98/ME/2000/XP/Vista/7/8
Supported browsers: IE6.0-10.0, Firefox, Safari, Google
Chrome
Supported mobile OS: iOS 4.3 and higher / Android 2.1 and
higher
Certification: CE, FCC, RoHS, R&TTE
