10
Installation and commissioning
7. INSTALLATION AND
COMMISSIONING
7.1. Safety Instructions
DANGER!
Danger of explosion!
• The device is a sealed system. The unit must not be dismantled!
The following safety regulations must be observed::
• The surface of the device may develop an electrostatic charge.
In areas with an explosion hazard, the surface of the units may
only be cleaned with a damp cloth!
• Only permanently laid cables and wiring may be inserted.
• The operator must provide suitable stress relief.
High voltage!
Acute risk of injury from hazardous structure-borne voltage!
Risk of damage to the device due to short circuit!
• Work on the electrical system may only be carried out by quali-
fied electricians!
• Before starting work, switch off the power supply and secure to
prevent it being switched on again!
• The connecting cables to the electromagnets must be secure,
and be laid so that they are adequately protected from mechani-
cal damage.
• Observe the applicable accident prevention and safety regula-
tions for electrical devices!
WARNING!
Pressurised system!
Interventions in the pneumatic system represent an acute risk of
injury.
• Work on the pneumatic system may only be carried out by quali-
fied and instructed personnel using appropriate tools.
• First switch off pressure before disconnecting lines and valves!
• Observe the flow direction during installation!
• Observe the applicable accident prevention and safety regula-
tions for pneumatic systems!
7.2. Montage
NOTES:
Installation in any position.
Preferably with solenoid system mounted at the top.
Activity Notes
→
Clean the pipe runs -
→
Installation in any position Preferred direction with drive
mounted at the top
→
Connect a dirt-trap
(strainer) upstream Note the direction of flow!
→
Seal PTFE
english
PTB 01 ATEX 2194 X
