03 ATEX1089 X - 11
english
The solenoid coils are mounted on the armature either with 4 stud screws M4x59
(flange version) or central fixing G 1/8 (plugged-on version).
They may be disassembled only by the manufacturer!
The valves always represent a closed system.
2.1.9. Special version solenoid Type 655-1.5.-...-.
• Rated voltage UC 12 ... 240 V
• Max. permissible voltage tolerance ±20 %
• Rated current 0.42 ... 0.025 A
• Limiting power consumption in equilibrium 5 W
• Temperature class
T5
• Ambient temperature -40 °C ... +40 °C
• Permissible installation individual assembly only
With these devices, a voltage tolerance of ±20 % is permissible.
They may only be installed in individual assembly.
2.1.10. Model with a terminal box
DANGER!
Risk of explosion!
•
Only permanently laid cables and wiring may be inserted.
• The operator must provide suitable stress relief.
• Wires with an outside diameter of 6 to 13 mm may be used. Observe
the maximum thermal loading of the cables or wires to be inserted.
• The inserted break-off seal must be matched to the diameter of the
cable or wire.
• The rated cross-section of the cable or wire strands must be at least
0.75 mm² and may not exceed 2.5 mm².
• The screws for fixing the cover of the terminal box must be tightened
with a torque of 100 Ncm (±5%).
The solenoid coils may also be executed with a terminal box, with or without fuse/
contactor (to separate Design Inspection Certificate) as desired.
For protection against inadvertent opening of the cover, the latter bears the marking:
Open only when the voltage is switched off!
