2-2
Section 2 Installation Installation and Operation Manual
X-PR-SLA7800-PC-eng
Part Number: 541B047AAG
December, 2008
Model SLA7800 & SLA7820
2-4 Return Shipment
Prior to returning any instrument to the factory, contact your nearest Brooks
location for a Return Materials Authorization Number (RMA#). This can be
obtained from one of the following locations:
Brooks Instrument
407 W. Vine Street
P.O. Box 903
Hatfield, PA 19440 USA
Toll Free (888) 554-FLOW (3569)
Tel (215) 362-3700
Fax (215) 362-3745
E-mail: [email protected]
www.BrooksInstrument.com
Brooks Instrument Brooks Instrument
Neonstraat 3 1-4-4 Kitasuna Koto-Ku
6718 WX Ede, Netherlands Tokyo, 136-0073 Japan
P.O. Box 428 Tel 011-81-3-5633-7100
6710 BK Ede, Netherlands Fax 011-81-3-5633-7101
Tel 31-318-549-300 Email: [email protected]
Fax 31-318-549-309
E-mail: [email protected]
Instrument must have been purged in accordance with the following:
Completion of form RPR003-1, Brooks Instrument Decontamination
Statement. A copy of this form can be downloaded from the Brooks website
www.brooksinstrument.com or is available from any Brooks Instrument
location listed above. This is required before any Brooks Personnel can
begin processing. Copies of the form can be obtained from any Brooks
Instrument location listed above. Provide a Material Safety Data Sheet
(MSDS) for the fluid(s) used in the instrument.
P the
2-5 Transit Precautions
To safeguard against damage during transit, transport the instrument to the
installation site in the same container used for transportation from the
factory if circumstances permit.
2-6 Typical Configurations
A pressure controller system can be built in upstream or downstream
control configurations (refer to Figures 1-5 and 1-6). When the controller is
placed downstream (upstream pressure controller) of the pressure vessel,
the flow is usually determined by the MFC(s) in the line upstream of the
vessel.
