-32- -31-
CAMERA ADJUSTMENT CAMERA ADJUSTMENT
PRIVACY OFF / ON
SETUP MENU
EXPOSURE AUTO
PICT ADJUST 
WHITE BAL ATW
WDR 
DNR 
DAY/NIGHT AUTO
PRIVACY 
MOTION DET 
OTHERS 
EXIT SAVE ALL
Hide an area so that it is not displayed on the monitor.
PRIVACY
AERA SEL 1 / 15
MODE OFF
POSITION -
COLOR -
TRANSP -
MOSAIC -
RETURN
AREA SEL: Selects the mask frame to be adjusted.
MODE: OFF / ON
When ON the settings below can be changed
Default all AREA are OFF
PRIVACY
AREA SEL 1 / 15
MODE ON
POSITION 
COLOR WHITE
TRANSP 1.00
MOSAIC -
RETURN
POSITION: When selected you are presented with a modification
selection as shown such as:
NEXT: PUSH ENTER
Moving left / right / up and down, you move
each of the four corners to create any irregular
rectangle. Press Enter will change to each to each of
the four sides and highlighted by a small square box
COLOR:
BLACK, RED, GEEEN, BLUE, YELLOW, CYAN, MAGENTA,
WHITE. Sets the colors of the mask frames.
TRANSP: 1.00 / 0.75 / 0.50 / 0.00 Sets the mask transparency.
MOSAIC: ON/OFF Sets the mask frame to show as mosaic.
This MOSAIC only available if TRANSP is not 1.00
MOTION DET OFF / ON
SETUP MENU
EXPOSURE AUTO
PICT ADJUST 
WHITE BAL ATW
WDR 
DNR 
DAY/NIGHT AUTO
PRIVACY 
MOTION DET 
OTHERS 
EXIT SAVE ALL
Motion Detection area of the screen, broken into 24 x 16 rectangle blocks. You
can use MONITOR AREA to give an always on detection area.
