eLine Technology EYS-VMS eyStream User Manual Part2 - Manual (Page 8)

108
flag will be shifted back from the actual time the alarm was triggered.
Note
If the alarm flag position is set, playback of an event received for
processing begins from the moment corresponding to the flag's
position, and not from the moment of the beginning of the alarm
b. In the Post-record time field (2), enter the post record time, which is the length in
seconds of post-alarm recording which will be added to the end of the recording made
in connection with the alarm. The post record time is counted from the moment of the
end of the alarm and is observed only if the alarm is evaluated by the operator before
the end of the given time. If the alarm is evaluated by the operator or automatically
after the end of the post record time, the recording ends at the moment of evaluation
of the alarm.
Note
Post-alarm time is 0 seconds by default
Note
For example, let's say that the post record time is 2 minutes. An
alarm is registered. If the operator evaluates the alarm before it is
over or within 2 minutes of the moment it ended, the recording will
end exactly 2 minutes from the moment the alarm ended. If the
alarm is evaluated by the operator or automatically after two minutes
have passed since the end of the alarm, the recording ends at the
moment of evaluation of the alarm
6. To save changes, click the Apply button.
Configuration of recording to the archive and initiation of an alarm when a detection tool is
triggered is now complete.
Switching to the layout with the minimum number of cells to display the
selected video camera
To configure the system to switch to the layout with the minimal number of cells for displaying the
selected video camera when a detection unit is triggered, create an Open layout automatic rule
(see
Adding an automatic rule ).
eLineTechnology.com 303.938.1133
