4.7 Condensates discharge
1. Mount a siphon in the condensates discharge pipe.
CAUTION
If there is no siphon, problems with condensates
discharge may arise when the compressor is running.
2. Mount the flow collector.
3. Fit the clamp to the flow header.
4.8 Installing the control system in the living room
The control system is mounted as standard on the heat pump. It is
possible to install the control system in the living room for greater
comfort.
4
The user can remotely control programming of DHW production.
4
The user is informed directly if the installation malfunctions in any
way.
4.8.1. Choose a location
Install the control system against an internal wall around 1.5 metres
from the floor in the carefully chosen pilot room.
Locations in the room that are not recommanded:
4
Encased
4
Exposed to solar radiation.
1
C
0
0
3
6
5
6
-B
min. 200
