Table c.1: system configuration descriptions – Avocent DSView 3 User Manual
Page 357
Appendices 335
Figure C.1: Using the DSR Remote Operations Software with a DSR Switch
Table C.1: System Configuration Descriptions
Number
Description
Number Description
1
CAT 5 Connection
7
Modem
2
KVM Connection to Switch
8
Analog User (OSCAR Interface)
3
Remote IP Connection
9
Ethernet
4
AC Power Cord
10
Telephone Network
5
Power Device
11
DSR Remote Operations Client
6
DSR Switch
12
DSView 3 Software Server (Authentication)
5
6
9
8
7
11
10
1
2
3
12
4
