Datamax-O'Neil Performance series Present Sensor User Manual
Page 9
2 | Present Sensor Installation
Present Sensor Installation Guide
8
Caution:
Ensure the ribbon cable is securely connected to the present sensor sub-
assembly. The cable should be routed upward through the opening in the
support mount.
Figure: 2 - 7 Present Sensor Assembly
Note:
The ribbon cable should be routed through the opening.
Front Panel
Present Sensor
Sub-Assembly
Support Mount
Ribbon Cable Opening
