Datamax-O'Neil Performance series Present Sensor User Manual
Page 4
3
Present Sensor Installation Guide
2
Present Sensor Installation
Tools Needed
•
2.5mm Hex Head Wrench
•
3mm Hex Head Wrench
•
7mm Nut Driver
•
#1 Phillips Screwdriver
•
#2 Phillips Screwdriver
Safety Overview
Caution:
Electrostatic discharge (ESD) protection is required when performing these
steps.
Warning:
The cover set may only be removed by a Datamax-O’Neil Authorized Service
Center. Unauthorized service will void the manufacturer’s warranty.
Warning:
The printer must be powered off and disconnected from utility power prior to
performing these procedures. Failure to heed this warning may result in personal injury
or damage to internal components.
•
Maintain complete ESD protection in a safe, clean environment at all times while
servicing this equipment. The installer must be properly grounded.
•
When handling the printhead, grasp it by its edges.
•
Avoid contact between the printhead and clothing.
•
Never pull on any wires to disconnect connectors. This can void the manufac-
turer’s warranty.
