Datamax-O'Neil Performance series Present Sensor User Manual
Page 10
Present Sensor Installation | 2
9
Present Sensor Installation Guide
12. Fasten the present sensor assembly to the printer front cover.
Figure: 2 - 8 Present Sensor Panel Installation
13. If not assembled, fasten the present sensor PCB assembly to the mounting plate
using the supplied screws.
Figure: 2 - 9 Present Sensor PCB Assembly
Media Cover Open
Front Cover
Ribbon Cable Connector
Extension
Cable Connection
