2 | Thermal Transfer Installation Guide
Thermal Transfer Installation Guide
8
9. Secure the ribbon spool cover to the printer frame with both (2) screws and
washers.
Figure: 2 - 7 Ribbon Spool Cover
10. If applicable, connect the cable to junction J1 of the ribbon transfer controller board.
Figure: 2 - 8 Ribbon Transport Power Connections
Screws
Washers
J3
J4
J1
