Datamax-O'Neil OC-2 SERIES User Guide - Manual (Page 13)

S
ETTING UP YOUR PRINTER
9
Connecting the printer via a cable or radio
The OC-2 printer is designed to transmit and receive data from
a host terminal. The host terminal may be your computer,
handheld, or laptop. Communication can occur using one of the
following methods:
•
Using a data cable to connect the printer and the host
terminal (this page), or
• Enabling wireless communication (see "Bluetooth and/or
802.11b parameters" on page 10).
Installing a data cable
1. Verify the printer settings before connecting the printer to a
host terminal. For more information, see "Printing a self-
test" on page 8.
2. Insert the data cable plug into the printer's data port
(Figure 26).
3. Connect the data cable to the host or device you are using.
Removing a data cable
1. Rotate the printer so that the printer's data port is visible.
2. Lift the cable connector's lever and remove the cable.
Figure 25 Figure 26
Data port
