OC-2 SERIES OF PRINTERS USER'S GUIDE
8
6. Close the printer (Figure 22). The printhead cover snaps
into place when completely closed.
7. Push the Media Function button 1-2 times to align the
media.
8. At either edge of the printer cover are serrated corners.
Tear the media by pulling up and away from the printer
(Figure 24).
Printing a self-test
1. Press and hold the power button for approximately three
(3) seconds until printing begins. For information on button
functions, see "Using the control panel" on page 12.
2. After printing begins, release the power button. A self-test
label will print showing parameters, as described on
page 10.
Warning: The tear bar and printhead cover surface may be
hot and/or sharp. Use caution when handling the printhead
and tear bar.
Figure 20 Figure 21 Figure 22
Figure 23 Figure 24
