S
ETTING UP YOUR PRINTER
7
Loading media
The OC-2 series of printers are designed to print receipt paper
and label media, as follows:
Load media as follows:
1. Position the printer so that the Datamax-O’Neil logo is facing
you (Figure 18).
2. Press the printhead release and open the printer
(Figure 19).
3. Place the paper roll between the paper roll holders, as
shown in Figure 20. Make sure the paper exits over the roll
and is firmly in place.
4. Unroll enough paper so that paper exits the printer
(Figure 21).
5. Verify the media exits straight and is against the right-hand
edge.
Media Guidelines
Media width Receipt Paper: 2.25”
Label Media: 2.25”
Roll capacity diameter Receipt Paper: 2.25”
Label Media: 2.25”
Media types Receipt paper media, thermal paper.
* Depending on the type of media
used, you may need to configure your
printer. For more information, see
"Configuring the printer" on page 10.
Figure 18 Figure 19
