GHM9

INCREMENTAL ENCODERS, GHM9 RANGE

OUTPUT ELECTRONIC / SUPPLY

2G2 electronic (100kHz)

Supply : 5Vdc

10%

Cons. without load : 100mA max
Current per channel : 40mA max

0 max (Is=20mA) : V

ol

= 0,5Vdc

1 min (Is=20mA) : V

oh

= 2,5Vdc


5G2 electronic (100kHz)

Supply : 11 to 30Vdc
Cons. without load : 75mA max
Current per channel : 40mA max
0 max (Is=20mA) : V

ol

= 0,5Vdc

1 min (Is=20mA) : V

oh

= 2,5Vdc


5G5 electronic (100kHz)
Supply : 11 to 30Vdc
Cons. without load : 75mA max
Current per channel : 40mA max

0 max (Is=20mA) : V

ol

= 0,5Vdc

1 min (Is=20mA) : V

oh

= Vcc-3Vdc


5GT electronic, optional (100kHz)

Supply : 11 to 30Vdc
Cons. without load : 75mA max
Current per channel : 40mA max
0 max (Is=20mA) : V

ol

= 0,5Vdc

1 min (Is=20mA) : V

oh

= Vcc-2,5Vdc

5GT electronic permits to drive very long (contact our factory)

Available in option :

- 3G3 electronic, supply between 15 and 30Vdc, push-pull output regulated 12Vdc
- 5GH electronic permits to drive different inputs (PLC + display for example)

Protection against short circuits for electronics: 5G5, 5GT, 3G3
Protection against polarity inversion for all electrics 2G2

‘’Option ‘’Max control’’ : the encoder gives on real time its physical environment parameters: shocks and vibrations, too high or too low
temperature, too low or too high supply, quality of the output signals : upon request..

STANDARD CONNECTION

-

+

A

B

0

A/

B/

0/

Ground

GB

Terminal box

1

2

3

4

5

6

7

8

On cable

gland

G6

12 pins CW

1

2

3

4

5

6

7

8

Connector

body

G8

12 pins CCW

10 + 11

2 + 12

8

5

3

1

6

4

Connector

body

G3

PVC cable 8

wires 8230/020

WH

white

BN

brown

GN

green

YE

yellow

GY

grey

PK

pink

BU

blue

RD

red

General

shielding

GP

PUR cable 12

wires 8230/050

WH white +

WH/GN white /green

BU blue +

BN/GN brown/green

GY

grey

BN

brown

RD

red

PK

pink

GN

green

BK

black

General

shielding

ORDERING CODE

(

Special versions upon request, for ex. over-speed switches, special flanges/electronics/connections…

)

Shaft

Available electronic

Output signal Resolution

Connection

Connection

orientation

GHM9

GBM9

Stainless steel
body

GXM9

Stainless steel
cover and body

11 : 11mm

12 : 12mm

C1 : 11mm

Length

20mm

C2 : 12mm

Length

25mm

2G2, 5G2, 5G5, 5GT, 5GH, 3G3

9 : A,A/,B,B/,0,0/
(0, A&B gated)

A : A,A/,B,B/,0,0/
(0, A gated)

N : A,A/,B,B/,0,0/

(0 ungated)


K : max

control option

10 000

max

G6: M23 12pins CW

G5: M23 12pins CW

G8: M23 12 broches

CCW

GB: terminal box

G1: solenoid 4pins

R : radial


A
: axial

Supply

Output stage

2 : 5Vdc

5 : 11 to

30Vdc

3 : 15 to

30Vdc

G2 : driver 5Vdc RS422

G3 : driver 12Vdc

G5 : push-pull

GT : push-pull 11-30Vdc

transistorized

GH : push-pull 11-30Vdc
150 mA

G3 : PVC cable 8

wires

GP
: PUR cable 12

wires

Example:

R020 : radial
cable 2m

A030 : axial
cable 3m

Ex: GHM9 _

11 //

5

G5

9 //

5 000 //

GP

R050


Available resolutions

: 1 2 3 4 5 6 7 8 9 10 12 13 14 15 16 19 20 21 24 25 26 28 29 30 32 35 36 39 40 43 45 46 48 50 54 56 58 60

62 63 64 66 67 70 72 74 75 76 80 84 86 88 89 90 91 94 96 100 107 110 120 122 123 125 127 128 130 132 135 138 140 147 150 157

159 160 168 169 170 172 175 180 188 191 196 200 201 205 220 222 225 234 240 241 242 245 246 248 250 254 255 256 258 259 267

268 275 283 285 295 300 305 314 315 318 320 330 340 350 360 367 375 378 380 381 388 390 397 400 405 410 424 425 438 443 450
471 480 489 495 500 505 512 515 534 540 550 565 580 600 623 625 628 630 632 635 650 660 700 720 746 750 752 754 800 810 840

860 880 891 900 942 990 1000 1024 1080 1100 1131 1200 1225 1250 1260 1280 1290 1400 1414 1440 1500 1536 1570 1600 1620 1630

1750 1800 1885 2000 2048 2250 2400 2500 2640 3000 3456 3600 3680 3750 4000 4096 4500 4900 5000 7200 9000 10000

Changes possible without further notice - Version 2.0

BEI Sensors SAS
Espace Européen de l’Entreprise
9, rue de Copenhague
B.P. 70044 Schiltigheim
F 67013 Strasbourg Cedex

Tél

: +33 (0)3 88 20 80 80

Fax

: +33 (0)3 88 20 87 87

Mail

:

[email protected]

Web

: www.beisensors.com
