12.1 HDCP
12. APPLICATIONS NOTE AND TIPS
HDCP is a content protection mechanism which uses encrpytion to prevent high value content from being
delivered to non-authorized devices. For example, Blu-ray players use HDCP on their HDMI outputs to ensure
that the HDMI output cannot be routed to a digital recording device.
Ascender 48 is fully HDCP compliant, meaning that you will be able to use the Ascender 48 to accept HDCP
protected sources and route them to any HDCP protected outputs. As Analog Way is a licenced HDCP adaptor,
this also means that the Ascender 48 is prevented from displaying any HDCP protected images on any non-
HDCP compliant outputs (as is the case for all licenced HDCP compliant devices).
HDCP can only be used on certain connection formats, including DVI, HDMI, and Displayport. Keep in mind
that simply because a connection is using a DVI, HDMI, or Displayport connection, it does not gaurentee
that the devices connected are maintaining an active HDCP connection. For example, you may find video
recording or capture devices equipped with an HDMI input, however HDCP licencing forbids these devices
from capturing HDCP protected content.
HDCP is not supported on connection formats such as composite, component, Svideo, SD-SDI, HD-SDI,
3G-SDI, or VGA. This means that any source which becomes protected by HDCP cannot be converted to
these formats. For example, while you may find a Blu-ray player which can directly output a composite video
signal, HDCP licencing forbids converting the HDCP protected HDMI signal back to composite or any other
non-protected format.
To help troubleshoot HDCP in your installation, Ascender 48 offers a convenient HDCP map as well as HDCP
status information. To access the HDCP map, use the Web RCS and navigate to the SETUP > CONTROL > HDCP
Map page. Each input and output page is also equiped with HDCP status information to indicate in realtime
when HDCP encryption is being used.
Certain devices such as Macintosh computers can be particularly tricky to use in conjunction with an HDCP
compliant presentation switcher such as the Ascender 48. This is because devices like the Mac computers can
be used to output both HDCP protected content (such as a movie downloaded from iTunes) as well as non-
HDCP protected content (such as a Keynote presentation or the desktop). When a computer first connects
to an HDCP compliant device such as the Ascender 48, it learns the capabilities of the device through the
EDID connection. Upon seeing the HDCP compatibility of the attached Ascender 48, devices like the Mac
computers will immediately attempt to use HDCP encrpytion at all times, despite the content currently
displayed on the computer screen. Since this source would now be considered as an HDCP protected source,
Ascender 48 would be required to prevent it from being displayed on VGA or SDI outputs and only allow it
to be displayed on outputs protected by HDCP. To work around this problem, Ascender 48 allows the HDCP
features of a particular input to be disabled, which in turn informs the Mac computer to avoid using HDCP,
and allows content such as Keynote and the desktop to be displayed, as this input will no longer use HDCP
protection. Please note that disabling the HDCP features of the input do not circumvent HDCP protections,
and thus do not allow you to view any content which requires this protection.
For more information about HDCP, please refer to our whitepapers on HDCP, or visit the HDCP foundation
website.
