I 0581 - 13 GB
5.4.2 - Out of balance optimization
- This function serves to reduce the amount of weight to be added in order to balance the wheel.
- It is suitable for static unbalance greater than 30 g.
(the led
OPT.
comes on ).
- It improves the residual eccentricity of the tyre.
- With a piece of chalk make a reference mark on the fl ange
and the rim
- With the aid of a tyre remover, turn the tyre on the rim by
180°
- Refi t the wheel in such a way that the reference marks on the
rim and the fl ange coincide.
- RH display: percentage reduction value
- LH display: actual static unbalance value which can be
reduced by rotation
- Mark the two positions of the rim and tyre, and turn the tyre
on the rim until the positions correspond in order to obtain
the optimization on the display.
RETURN TO MEASUREMENT SCREEN.
RIM POSITION
TYRE
POSITION
Unbalance already measured No previous
unbalance measurement
unbalance measurement
