CEMB USA K9 (B) User Manual

Page 9

I 0672

- 9

►

.2.3 -

EXACT POSITIONING OF THE ADHESIVE WEIGHT BY MEANS OF THE GAUGE WITH CLIPS

Press the button

if using the correction method with weights on the inside of the rim

▪

Fit the correction weight in the specifi c gauge seat with the

adhesive part facing upwards

▪

Bring the wheel into correct angular position for the plane to be

corrected.

▪

Pull the gauge further outwards.

▪

Return the gauge to the rest position.

▪

INSIDE CORRECTION POSITION

▪

OUTSIDE CORRECTION POSITION

▪

When the weight application distance has been reached a

beep is sounded (can be deactivated).

▪

rotate the gauge until the correction weight adheres to the rim

▪

the fact that the weight application position is no longer vertical

(see

fi gure) is automatically compensated

▪

to cancel this function, press

button again.
