I 0615 - 9
6
6a
GB
5.2.1.1 - Static & combined modes
After calibration as per STEEL OR ALUMINUM WHEEL RIMS. SPRUNG COUNTERWEIGHTS , it is possible to modify the
position of the correction weights using the / buttons.
►
5.2.2 - Rims with internal counterweight ►
STATIC: Select by pressing
Balancing of light alloy rims with application of adhesive weights
on the shoulders of the rims.
Combined balancing: adhesive weight on the outside and clip-on
weight on the inside.
Combined balancing: adhesive weight on the inside and clip-on
weight on the outside.
Slide out the gauge on the LH side, at the point where a weight is
to be fi tted. Wait until the symbol shown in Figure 5d is displayed. Pull
it out further towards the right plane and wait until the symbol shown
in Figure 6a is displayed. The wheel balancer automatically identifi es
ALUS mode.
Counterweight position automatically suggested .
can be used to set the alternative position indicated.
