1- GENERAL

1.1 - GENERAL SAFETY REGULATIONS

- The wheel balancing machine should only be used by duly authorized and trained personnel.
- The wheel balancing machine should not be used for purposes other than those described in

the instruction manual.

- Under no way should the wheel balancing machine be modifi ed except for those modifi cations

made explicitly by the manufacturer.

- Never remove the safety devices. Any work on the machine should only be carried out by

specialist personnel.

- Avoid using strong jets of compressed air for cleaning.
- Use alcohol to clean plastic panels or shelves (AVOID LIQUIDS CONTAINING SOLVENTS).
- Before starting the wheel balancing cycle, make sure that the wheel is securely locked on the

adapter.

- The machine operator should avoid wearing clothes with fl apping edges. Make sure that

unauthorized personnel do not approach the machine during the work cycle.

- Avoid placing objects inside the base as they could impair the correct operation of the machine.

1.1.1 - STANDARD SAFETY DEVICES
- Stop push button for stopping the wheel under emergency conditions.
- Highly shock resistant plastic guard whose shape and size are designed to avoid the danger of

counterweights spinning off in any direction except downwards.

- A microswitch will not let the machine start up if the guard is not down and stops the motor

whenever the guard is raised.

1.2 - FIELD OF APPLICATION

The machine is designed for balancing wheels of car, light commercial vehicles or motorcycle, weighing
less than 65 Kg. It can be operated in the temperature range of 0° to + 45° C.
The following functions are provided: Double operator; ALU-S ( automatic only with C61Z ); SPLIT;
Unbalance optimization; Self diagnostics; Self-calibration

1.3 - OVERALL DIMENSIONS

Fig. 1 (standard guard)
