I 0184 - 14 GB
5.4.3 - UNBALANCE OPTIMIZATION
- This function serves to reduce the amount of weight to be added in
order to balance the wheel
- It is suitable for static unbalance exceeding 30g.
- It improves the residual eccentricity of the tyre.
RIM POSITION
TYRE
POSITION
- Mark with chalk a reference point on the adapter and rim
- With the aid of a tyre remover, turn the tyre on the rim by 180°
- Refi t the wheel with the reference mark coinciding between rim and
adapter
- RH display: percentage reduction
- LH display: actual static unbalance which can be reduced by rotation
- Mark the two positions (rim and tyre) and turn the tyre on the rim until the
positions correspond in order to obtain the optimization on the display
RETURN TO START OF OPTIMIZATION
RETURN TO MEASUREMENT SCREEN
